Bucket Elevator
Application
Bucket elevator as the main part of the packing line to lifting the products from low to combination scale or other equipment, especially suitable for the workshop with limited space.
Whether your product is coffee, frozen raspberries, or potato chips, you want to make it at the highest possible quality and with packaging that sets you apart from the competition.
Our machines are able to transport a large variety of products. Select and explore our solutions for your product.
Features
- Standard Discharge Height: 3200m
- Standard In-Feed Length: 863mm
- Standard Out-Feed Length: 1930mm
- Variable Speed Control: As required
- Frame Material: Stainless Steel/ Painted Steel
- Bucket Selection: 1L, 1.8L, 3.8L and 6.5L
- Machine type: Z type, C type and multiple discharge outlets
Control System
Z type bucket elevator comes with a control panel, including stop, work, run, emergency stop, auto/manual, speed adjustable and inching which is to aim to removal and installation the buckets. The control panel of the Z bucket elevator has two terminals for wire the combination scale, these are for controlling the Z bucket conveyor running or stopping automatically by using the sensor.
Product Suitability
Bucket conveyors are ideal for most types of products as the buckets are capable of holding and transporting both dry and wet products as well as granules and powders. The buckets are food grade standard material.
Working Video For Z Type Bucket Elevators For Different Products
- Space-saving conveying solution serving factory specification
- Flexible integration in the production line
- Top-quality components, Schneider, etc.
- Easy, user-friendly operation
- Sizes based on requirements of customers
- Other advantages occur in the simple and intuitive operation of the machines leading to short familiarization periods and trouble-free usage.
Custom Build
If the product requests to be washed frequently can consider using the belt conveyor. because it can be washed down directly, or even change to a spare belt, no stop production.
Capacity
| Buckets | 1L | 1.8L | 3.8L | 6.5L |
| Conveying Capacity | 1-3cbm/h | 4-6cbm/h | 6-8cbm/h | 10-12cbm/h |
Bucket Elevators Options
all the sizes can be customized……
Turn-key Solutions
We Made
We can custom-build the bucket elevator conveyors for you base on your 2D or 3D drawings. We can design a elevator base on your factory height and room space also. Contact us for a solution.
